Sherman TIG 210 AC / DC pulse inverter welder SET

The TIG 210 AC / DC pulse welder is an inverter device made in the IGBT technology. It is used for manual welding with direct and alternating current TIG and direct current with a coated electrode (MMA method). It is widely used in both production and service works. It is designed to work in closed and roofed rooms.


The welder allows full adjustment and control of all welding parameters of the arc and pulse characteristics. It has HF ignition, 2T / 4T function and welding current display. The device has excellent welding properties and is especially recommended for professionals.


The set includes a gas-cooled TIG welding torch and a return cable with a clamp.


TECHNICAL DATA:

    • Catalogue code: SINW-TIG210ACDCPSETPED
    • Supply voltage [V]: AC 230 50Hz
    • Welding methods: TIG AC / DC, MMA
    • The technology: IGBT
    • Welding current [A]: TIG: 200 / MMA: 180
    • Duty cyclle [%]: 60
    • Tension without load. [V]: 70
    • Max. current consumption [A]: TIG: 36.5 / MMA: 26.8
    • Max. power consumption [KVA]: 4.6
    • Adjust welding current: Liquid
    • Gas post flow [s]: 0.1-1
    • Gas post flow [s]: 0-15
    • Rising current [s]: 0-10
    • The current will drop [s]: 0-25
    • Initial current [A]: 10-200
    • Base current [A]: 5 - 95% of the welding current
    • Crater current [A]: 10-200
    • Pulse frequency [Hz]: 0.5-5; 10-200
    • Pulse duration [%]: 10-90
    • AC frequency [Hz]: 40-200
    • AC balance [%]: 10-90
    • Weight [kg]: 33
    • Dimensions (D x W x H) [mm]: 510 x 235 x 510



FUNCTIONS:

    • HF,
    • 2T / 4T,
    • Upslope,
    • Downslope,
    • Pulse,
    • Gas pre-flow and post-flow time adjustment,
    • Electrode cleaning function,
    • Welding current frequency adjustment,
    • AC welding


Equipment:

    • Sherman TIG 210 AC / DC pulse welder inverter with 2 pin EU style plug
    • Welding torch Tecweld T-26 / 4m Ergo Digitec 3p
    • Ground wire with a clamp
    • Protective welding work gloves
    • Professional self darkening welding mask
    • Argon Gas Bottle full of 99.99% Argon gas purity 8L 1.8m3 150Bar
    • Gas Regulator with manometer
    • Foot pedal controller
    • Tig torch consumables (tip, nozzle, colette)
    • Hose
    • Manual in Polish, English version available on request
    • Warranty card (2 years for end customers / 1 year for businesses)


Please note that the machine includes European/Continental plug, you need to arrange the UK one.
