Sherman TIG 320 AC / DC pulse welding set

The TIG 320 AC / DC pulse is an inverter welding machine made in the IGBT technology. It is used for manual welding with direct and alternating current TIG and direct current with a coated electrode (MMA method). It is widely used in both production and service works. It is designed to work in closed and roofed rooms.


The welder allows full adjustment and control of all welding parameters of the arc and pulse characteristics. It has HF ignition, 2T / 4T function and welding current display. The device has excellent welding properties, recommended especially for professionals.


The set includes: a liquid-cooled TIG welding torch, a ground cable with
 a clamp, an MMA electrode cable, a welding shield and a hammer.

The set includes:
- TIG 320 AC / DC pulse welder
- WRC 300B cooler
- TIG / MIG welding cart

TECHNICAL DATA:

    • Catalogue code: ZESTTIG320ACDCP
    • Supply voltage [V]: AC 3x400 50Hz
    • Welding methods: TIG AC / DC, MMA
    • Welding current [A]: TIG: 320A / MMA: 270A
    • Tension without load. [V]: 65
    • Cooler supply voltage [V]: AC 230V 50Hz
    • Cooling liquid pressure [MPa]: 0.3
    • Cooling liquid flow [l / min]:  8
    • Max. current consumption [A]: 13.7
    • Tank capacity [l]: 6
    • Load capacity of the trolley [kg]: 70


FUNCTIONS:

    • HF,
    • 2T / 4T,
    • Upslope,
    • Downslope,
    • Gas pre-flow and post-flow time adjustment,
    • Electrode cleaning function,
    • Welding current frequency adjustment,
    • AC welding

Equipment:

    Sherman TIG 320 AC/DC pulse
    Welding holder T-18 / 4m
    Mass cable
    Manual in Polish, English version available on request
    Warranty card (2 years for end customers / 1 year for businesses
